VII. Specifications
Model name
Mountable objective
number
Objective switching
method
Dimensions
Joint part to the
microscope
Slot for the DIC slider
Slot for the lambda
plate slider
Interface
Operating condition
Storage condition
LV-NU5AI U5AI Motorized Nosepiece
5
Rotating the motorized nosepiece
Nosepiece drive device: center motor
Switching time: approximately 0.5 seconds
Overall height: 88.9 mm
Outer diameter: 127 mm
Inclination angle: 15°
Dimension of objective thread: M32 x 0.75 mm
Distance between the attachment position of the objective barrel and the attachment
reference position of the nosepiece: 53 mm
Sliding dovetail (reference dimension: 50 mm)
Dovetail, five locations (Each objective address has a slot for it.)
Slot size: 16.5 mm x 24 mm
Built-in swing-out mechanism for the bright-field/dark-field optical path separation ring
(interlocked with the lambda plate slider insertion)
Connector of 12-pin
Temperature: 0°C to +40°C
Humidity: 85% relative humidity maximum (no condensation)
Altitude: 2000 m maximum
Pollution degree: Degree 2
Installation category: Category II
Electric shock protection class: Class III
Indoor use only
Temperature: -20°C to +60°C
Humidity: 90% relative humidity maximum (no condensation)
LV-NU5AI
