Getting Started
7
Indications in the viewfinder
1Parallax compensation marks
For shooting in Macro mode at a distance of approx.
0.6 m (2.0 ft.).
2Autofocus frame marks ( p. 15)
Center the main subject to be in focus within this frame.
3Red LED
Momentarily lights: Focus is achieved.
When you press the Shutter Release
button, the shutter is released, but
the flash does not fire.
Lights up: Focus is achieved and the flash is
ready to fire.
When you press the Shutter
Release button, the flash fires.
Blinks: The flash is being charged.
The Shutter Release button is
disabled.
Quick blinks: The flash dose not fire.
If the popped-up flash unit is
inadvertently pressed down, the
LED quickly blinks as a warning.
Does not light: The camera-to-subject distance is
too short.
Move further way than approx.
0.9 m (3.0 ft.) with the wide-angle
setting or 1.2 m (3.9 ft.) with the
telephoto setting.
2
3
1
