MC 5M - MC 6P - MC 7P
2.3 Operating elements 1. Push/pull handle
2. Spray gun
3. Electrical lead
4. Holder for high pressure hose
5. High-pressure hose
6. Fastening screw
7. Lance
1)
8. Parking brake
1)
9. High-pressure hose connection (on standard models without hose
reel)
1)
10. Water connection and water inlet filter
11. Oil inspection slide
12. Pressure gauge
1)
13. Main switch
14. Chemical dosing regulation
1)
15. Water flow regulation
1)
16. Chemical tank
1)
17. Cover lock
1
5
4
3
16
6
4
7
2
14
12
11
13
15
10
8
9
17
