INSTRUCTIONS FOR USE ENGLISH
9099980000 - SC500 7
11/2014
21. Washing water tank
22. Washing water tank front ller
23. Water removable ller hose
24. Washing water tank side ller cap
25. EcoFlex™ detergent tank (*)
26. Disc brush deck
27. Brush
28. Front driving wheels
29. Squeegee
30. Debris collection tank
31. Vacuum grid with automatic shut-off oat
32. Vacuum system motor
33. Recovery tank
34. Recovery water tank cover (open)
35. Machine straight forward movement adjusting knob
36. Batteries (optional)
37. REV™ deck (**)
38. REV™ brush (**)
(*) Not for SC500 20D B version
(**) For REV™ version only
MACHINE STRUCTURE (Continues)
30
24
21
36
29
28
31
34
32
22
23
25
35
26
27
33
37
38
P100854
9099980000(2)11-2015.indb 7 05/11/2015 15:58:43
