A-24 / ENGLISH
A-24 - FORM NO. - 56041820 - SC750, SC800, SC750 ST, SC800 ST
TECHNICAL SPECIFICATIONS (as installed and tested on the unit)
Model SC750-26D
SC750 ST-26D SC750-28D
SC750-28C SC750 ST-28D SC750-28R
Model No. 56112000
56112012 56112004
56112006 56112013 56112780
Voltage, Batteries V 24V 24V 24V 24V
Battery Capacity Ah 312 312 312 312
Protection Grade IPX4 IPX4 IPX4 N/A
Sound Pressure Level
(IEC 60704-1)
dB(A) 61 61 61 64
Sound Pressure Level
(IEC 60704-1) Uncertainty
dB(A) 3.0 3.0 3.0 3.0
Gross Weight lbs / kg 942/427.3 942/427.3 942/427.3 969/439.5
Transport Weight lbs / kg 932/422.7 932/422.7 932/422.7 959/435.0
Maximum Wheel Floor Loading (right front) psi N/mm
2
59.08/0.407 59.08/0.407 59.08/0.407 56.88/0.392
Maximum Wheel Floor Loading (left front) psi N/mm
2
60.10/0.414 60.10/0.414 60.10/0.414 69.61/0.480
Maximum Wheel Floor Loading (center rear) psi N/mm
2
287.56/1.983 287.56/1.983 287.56/1.983 268.39/1.85
Vibrations at the Hand Controls
(ISO 5349-1)
m/s
2
Less than 2.5 Less than 2.5 Less than 2.5 Less than 2.5
Vibrations at the Hand Controls
(ISO 5349-1) Uncertainty
m/s
2
.02 .02 .02 .02
Gradeability Transport 2% (1.15º) 2% (1.15º) 2% (1.15º) 2% (1.15º)
Gradeability Cleaning 2% (1.15º) 2% (1.15º) 2% (1.15º) 2% (1.15º)
Model
SC800-28D SC800-32C
SC800-28C SC800-34D SC800 ST-34D
Model No.
56112016 56112024
56112018 56112028 56112032
Voltage, Batteries V
24V 24V 24V
Battery Capacity Ah
312 312 312
Protection Grade
IPX4 IPX4 IPX4
Sound Pressure Level
(IEC 60704-1)
dB(A) 61 61 61
Sound Pressure Level
(IEC 60704-1) Uncertainty
dB(A) 3.0 3.0 3.0
Gross Weight lbs / kg 994/450.9 994/450.9 994/450.9
Transport Weight lbs / kg 984/446.3 984/446.3 984/446.3
Maximum Wheel Floor Loading (right front) psi N/mm
2
71.0/.490 71.0/.490 71.0/.490
Maximum Wheel Floor Loading (left front) psi N/mm
2
66.6/.459 66.6/.459 66.6/.459
Maximum Wheel Floor Loading (center rear) psi N/mm
2
287.6/1.983 287.6/1.983 287.6/1.983
Vibrations at the Hand Controls
(ISO 5349-1)
m/s
2
.09 .09 .09
Vibrations at the Hand Controls
(ISO 5349-1) Uncertainty
m/s
2
.02 .02 .02
Gradeability Transport 2% (1.15º) 2% (1.15º) 2% (1.15º)
Gradeability Cleaning 2% (1.15º) 2% (1.15º) 2% (1.15º)
MATERIAL COMPOSITION
LBS KG
Aluminum 13.58 6.16
Rubber 15.888 7.21
Plastic 23.037 10.45
Polyethylene 116.4 52.79
Ferrous Metal & Copper
Transaxle 23 10.43
Brush Motor 17.25 7.82
Vac Motor 6 2.72
Other Electric 19.41 8.80
