SOL 3 / SOL 5 W / BDC 3122 / BDC 3140 / E-VAC3000
3
03/2009
GB
Vacuum cleaner description
Optional kits
Various optional kits are available for converting the vacuum
cleaner:
■ Level gauge for liquids suction/stop
■ Removable separator
On request, the vacuum cleaner can be supplied with optional
kits already installed. However, they can also be installed at a
later date.
Please contact the manufacturer’s sales network for further
details.
Instructions to install parts on request are included in the
conversion kit.
WARNING!
Use only genuine optional supplied and authorized by
the manufacturer.
Accessories
Various accessories are available; refer to the manufacturer’s
accessory catalogue.
WARNING!
Use only genuine accessories supplied and
authorized by the manufacturer.
Packing and unpacking
Dispose of the packing materials in compliance with the laws
in force.
Figure 2
Model A (mm) B (mm) C (mm) Kg
SOL 3 / BDC 3122 1,200 700 1,700 122
SOL 5 W / BDC 3140
/ E-VAC3000
1,200 700 1,700 147
Labels
Figure 1
1 Identication plate
Code of the model which includes technical
specications, serial number, EC marking, year of
manufacture
2 Suction union hose
3 Control panel (normal version)
4 Control panel (version for vacuuming liquids)
5 Dust container
6 Filtering chamber
7 Exhaust
8 Attention plate
Draws the operator’s attention to the fact that the lter
must only be shaken when the vacuum cleaner is off.
Failing this, the shaking would have no effect while the
lter itself could be damaged.
9 Panel power plate
Indicates that the panel is powered by the voltage given
on the data plate.
10 Inlet
This vacuum cleaner creates a strong air ow which is drawn
in through the inlet (10) and blows out through the exhaust
(7). After the hose and tools have been tted, make sure that
the motor turns correctly.
Before turning on the vacuum cleaner, t the vacuum hose
into the inlet and then t the required tool on to the end part.
Refer to the manufacturer’s accessory catalogue or Service
Centre.
This vacuum cleaner is equipped with an internal bafe
plate which subjects the vacuumed substances to a circular
centrifugal movement that makes them drop into the
container. The vacuum cleaner is equipped with a lter which
enables it to be used for the majority of applications.
