03/2009
6
SOL 3 / SOL 5 W / BDC 3122 / BDC 3140 / E-VAC3000
GB
Controls, indicators and connections
Figure 4
1 Container release lever
2 Castor lever
3 Manual lter shaker knob
4 Start/stop switch (normal version)
5 Start/stop switch (version for vacuuming liquids)
Inspection prior to starting
Figure 5
1 Inlet
Prior to starting, check that:
■ The lter is installed.
■ All latches are tightly locked.
■ The vacuum hose and tools have been correctly tted
into the inlet (1).
■ The bag or safety container is installed, if applicable.
Do not use the vacuum cleaner if the lter is faulty.
Starting up
Figure 6
1 Castor brakes
2 Start switch (normal version)
3 Start switch (version for vacuuming liquids)
Lock the castor brakes before starting the vacuum cleaner (1).
Starting/stopping the vacuum cleaner
Normal version
■ Turn the switch (2) to “I” position to start the vacuum
cleaner.
■ Turn the switch to “0” position to turn the vacuum cleaner
off.
Version for vacuuming liquids
■ Turn the switch (3) to “I” position to start the vacuum
cleaner.
■ Turn the switch to “0” position to turn the vacuum cleaner
off.
Technical data
Parameter
Unit
SOL 3
SOL 5
W
E-VAC3000
BDC 3122 BDC 3140
Voltage (50 Hz) V
230/400 230/400 230/400 230/400
Power rating kW
2.2 4 2.2 4
Noise level dB(A)
71 74 71 74
Protection IP
55 55 55 55
Insulation Class
F F F F
Capacity L
60/100 60/100 100 100
Inlet (diameter) mm
70 70 70 70
Max vacuum mmH
2
O
3000 3000 3000 3000
Maximum
air ow rate
(without hose
and reductions)
L/min’
5100 8600 5100 8600
Main lter
surface
m
2
1.95 1.95 1.95 1.95
Dimensions
Figure 3
Model SOL 3
SOL 5 W
E-VAC3000
BDC 3122 BDC 3140
A (mm)
L 60 1330 1330 / /
L 100 1530 1530 1530 1530
B (mm) 1055 1055 1055 1055
C (mm) 670 670 670 670
Kg (1) 102 127 102 127
(1) Net weight
[ NOTE ]
■ Storageconditions:
Temperature:-10°C÷+40°C
Humidity:≤85%
■ Operatingconditions:
Maximumaltitude:800m
(Upto2,000mwithreducedperformances)
Temperature:-10°C÷+40°C
Humidity:≤85%
