154Service Manual – SW5500, FLOORTEC R 985 28 - Engine System, Diesel
Engine Oil Level Check
WARNING: Running the engine with a low oil level can damage the engine itself.
1. Drive the machine on a level oor.
2. Turn the ignition key to “0”, then engage the parking brake.
3. Open the engine compartment hood with the handle and fasten it with the support rod.
4. Lift and remove the machine left side panel, disengaging it from the upper and lower fasteners.
5. Remove the cap (A).
6. Check the oil level. If it is below the upper limit (B), top up with the recommended oil until you reach
the upper limit.
7. Reinstall the ller cap (A) safely.
8. Perform steps 3 and 4 in the reverse order.
A
B
C
E
D
DIESEL VERSION
LPG VERSION
Figure 5:
B
A
