Nilfisk-ALTO SCRUBTEC 343.2 User Manual

USER MANUAL ENGLISH
9099636000 - SCRUBTEC 343.2 7
FRONT OF
MACHINE
BACK OF
MACHINE
PANEL
12V
12V
PANEL
41
42
54
46
50
53
44
51
58
43 45
47
55
48
49
52
56
57
P100637
MACHINE STRUCTURE (Continues)
41. Recovery water tank cover (open)
42. Recovery tank cover gasket
43. Front brush/pad-holder support
44. Recovery tank compartment
45. Solution tank ller neck
46. Vacuum grid with automatic shut-off oat
47. Safety rod for open cover
48. Vacuum system motor
49. Brush/pad-holder motor
50. Batteries
51. Battery connection diagram
52. Machine straight forward movement adjusting handwheel
53. Machine forward speed adjusting handwheel
54. Brush
55. Pad-holder
56. Pad
57. Brush rotation direction
58. Lifted squeegee
