USER MANUAL ENGLISH
9099636000 - SCRUBTEC 343.2 13
BEFORE MACHINE START-UP
Brush or pad-holder installation
NOTE
Use either the brush (54) or the pad-holder (55 and 56) according to the type of oor to be cleaned.
1. Insert the positioning pin (24) and disengage the machine transport/parking device (23b).
2. Lift the brush/pad-holder deck (10) by prying the handlebar (2).
3. Place the brush (54) or the pad-holder (55 and 56) under the deck.
4. Lower the deck (10) by using the handlebar (2).
5. Turn the switch (62) to “I”.
6. Press the brush enabling push-buttons (61) to engage the brush/pad-holder to the deck hub (10). If necessary, repeat the
procedure until the brush/pad-holder is engaged.
Available brushes and their relevant application guides (suggestions only)
Models MIDLITE GRIT 180 MIDGRIT 240 PROLITE UNION MIX
General cleaning
Concrete
Terrazzo oor
Ceramic tiles/quarrystones
Marble
Vinyl tiles
Rubber tiles
Polishing
Rubber tiles
Marble
Vinyl tiles
Squeegee installation
7. Install the squeegee (11) and fasten it with the handwheels (12), then connect the vacuum hose (22) to the squeegee.
Solution tank lling
CAUTION!
Use only low-foam and non-ammable detergents, intended for automatic scrubber applications.
WARNING!
When using oor cleaning detergents, follow the instructions on the labels of the detergent bottles.
To handle oor cleaning detergents, wear suitable gloves and protections.
8. Use the ller neck (45) to ll the tank (31) with a solution suitable for the work to be performed. Do not ll the solution tank
completely, leave few centimetres from the edge. Always follow the dilution instructions on the label of the chemical product
used to prepare the solution. The solution temperature must not exceed 40°C.
