ENGLISH USER MANUAL
16 SCRUBTEC 343.2 - 9099636000
Machine speed adjustment
4. The machine speed varies according to the type of oor to be cleaned and the choice of using the brush or the pad. If
necessary, it is possible to adjust the machine speed, according to the procedure shown in Maintenance chapter.
Battery discharge during operation
5. Until the green LED (64) turns on in the rst 5 seconds, the batteries allow to work normally. When the yellow and red LED turn
on in sequence, it is necessary to charge the battery as the machine residual autonomy is at the minimum level.
CAUTION!
Do not use the machine with discharged batteries, to avoid damaging the batteries and reducing the battery life.
MACHINE TRANSPORT/PARKING
To transport/park the machine, proceed as follows.
1. Turn off the machine by pressing the switches (62) and (63) to “0”.
2. Lift the squeegee (59).
3. Engage the positioning pin (24) and activate the machine transport/parking device (23a) to keep the brush/pad-holder lifted
(Fig. 5).
4. While holding the machine in this position, drive it to the transport/parking area.
5. In order not to drag the brush/pad on the oor and leave wet marks, when nishing working, remove the brush/pad-holder from
the deck by using the disengagement procedure (see the next paragraph), then place it on the front holder (43).
Figure 5
P100644
Brush/pad-holder removal
Remove the brush/pad-holder deck by performing the following procedure:
1. Turn the switch (62) to “I”.
2. Lift the brush/pad-holder deck (10) by prying the handlebar (2).
3. Press the switches (61) 3 times consequently, then wait that the brush starts and stop, thus disengaging from the drive hub.
4. Turn the switch (62) to “0” position to switch off the machine.
TANK EMPTYING
An automatic oat shut-off system (46) turns off the vacuum system when the recovery tank (30) is full.
The vacuum system shutdown, due to the recovery tank lling, is signalled by an increase in the vacuum system motor noise,
moreover the oor is not dried.
CAUTION!
If the vacuum system turns off accidentally (for example, when the oat is activated because of a sudden
machine movement), to resume the operation: turn off the vacuum system by turning the switch (63) to “0”, then
open the recovery tank cover (41) and check that the oat inside the grid (46) has gone down to the water level.
Then close the recovery tank cover (6) and turn on the vacuum system by turning the switch (63) to “I” position.
When the recovery tank (30) is full, empty it according to the following procedure.
