15
Mounting the Operation Bar
1. Mount the handlebar/to the operation bar by fastening the six
M4 x 8 hexagon flat cap head screws using the appropriate hex
wrench included with the Ninebot.
2. Insert the operation bar, with handlebar attached, into the
mainframe.
3. Secure the operation bar by tightening the quick release knob
in the clockwise direction (2-4 Nm).
Figure 6: Attach the handlebar.
Figure 7: Mount the Operation Bar to the Mainframe.
