Ninglu AM706D - Technical Requirements; Basic Parameters; Environmental Conditions; Technical Parameters

5
Technical Requirements
Basic Parameters
Dimension： 10 inch TFT
Display： Wind direction, speed, temperature,
humidity, barometric pressure, print
interval, alarm setting.
Wind direction simulation range： ±180°
Wind direction simulation accuracy： ±1°
Input/output port： Wind direction/speed input: 1 channel
DC power input： 2 channels
Temperature-humidity input： 1 channel
NMEA0183 input： 3 channels
NMEA0183output： 2 channels
Printer output： 1 channel
Sound-light alarm output： 1 channel
Power supply： DC24V (20~32V)
One channel power through adapter： 110/220V 50/60Hz AC
Environmental Conditions
Operating
temperature
Storage
temperature
Relative
humidity
Water
proof
Main unit
-15°C～+55°C
-20°C～+70°C
10%～90%
IP23
Wind sensor
-15°C～+85°C
-20°C～+85°C
10%～100%
IP56
Temperature
humidity sensor
-20°C ～+80°C
-20°C ～+80°C
0%～100%
IP54
