Installation of Wind sensor AM706S
Wind Vane and Wind Cup Installation
[ Wind Vane ] Wind vane is installed on the top of sensor holder,
successively into black seal ring, plane washer, spring washer and 2 screw
nuts. The two screw nuts should be tightened and then insert the cotter.
[ Wind Cup ] Wind cup is installed on the bottom of sensor holder,
successively into plane washer, spring washer and 2 screw nuts. The two
screw nuts should be tightened and then insert the cotter.
