Introduction
Introduction
The marine weather station AM706D is a multi-functonal
measuring instrument with wind speed, direction, temperature,
humidity and barometric pressure. It can accurately measure and
display real-time relative wind speed and direction, true wind speed
and direction, air temperature, relative humidity and barometric
pressure. In addition, it can regularly print these parameters and
time, longitude and latitude, ship speed, and navigational signal. It is
important and necessary for observation and safe navigation.
AM706D is approved by China Classification Society (CCS).
The main unit AM706D adopts three mounting methods, table,
hung and flush mounting. The wind sensor AM706S should be
installed on natural ventilated place, such as mast. Please note, big
Radar antenna rotation can disturb the wind measurement. The
AM706TH is suggested to be mounted on a place there is no direct
sunlight and rain drop.
