Symbols explanation
Responsiblemanufacturer
Theproductmeetstherequirements
of applicable European directives
ConformstoANSI/AAMIES60601-1
andcertiedtoCAN/CSAC22.2No.
60601-1
ElectricalsafetyTypeBappliedpart
100-240V~50-60Hz
Theproductshouldberecycled
accordingtothelocalprogramfor
electronicequipment.
Consultinstructionsforuse
Refertoinstructionmanual/booklet
Expiration date
Transportandstoragetemperature
limitation
Forsingleuseonly
Invitrodiagnosticmedicaldevice
12M
Durability-periodafteropening
Hazardousmaterial
ClassIIequipment
Backplate
NIOX MINO
®
Article No 09-1000
Circassia AB
Hansellisgatan 13, SE-754 50, Uppsala, Sweden
www.circassia.com
Use Only Power Supply Unit Art No 09-1005
Rated Supply Voltage 6 V
Maximum Rated Power 20 VA
U.S. Patent: 5,447,165 / 5,922,610 / 6,038,913 / 6,099,480 / 6,723,056 /
6,761,185 / 7,014,692 / D496,667 / D492,035 / D457,231
1 2 3 4 5 6 7
1. Responsiblemanufacturer
2. Refertoinstructionmanual/booklet
3. Invitrodiagnosticmedicaldevice
4. TypeBappliedpart
5. Theproductshouldberecycledaccordingto
thelocalprogramforelectronicequipment
6. Theproductmeetstherequirementsof
applicable European directives
7. ETL-Listed.ConformstoANSI/AAMIES60601-
1andcertiedtoCAN/CSAC22.2No.60601-1.
Base label
2 3
1
1. Instrumentexpirationdate(year:month)
2. Instrumentarticlenumber
3. Instrumentserialnumber
Dimensions and weight
Height:230mm
Width:128mm
Depth:96mm
WeightofinstrumentincludingSensor:0.8kg
Electrical data
Electricalsafetyclassication:Theequipment
complieswiththerequirementsaccordingtoIEC
61010-1and60601-1ClassIITypeB.
NIOX MINO instrument
Secondaryvoltage(externalpoweradapter):6V
Powerconsumption:<15VA
Power supply unit
MainsVoltage:100-240V~50-60Hz
Noise level (stand by)
<35dBA,atadistanceof1m
Shelf-life
NIOX MINO
®
instrument:Minimum3yearsattime
ofdelivery,or3,000measurements.
NIOXMINOSensor:Maximum12monthswhen
installed in NIOX MINO or expiration date as stated
ontheSensor,whichevercomesrst.
AlwaysusetheNIOXMINOBag(closed)for
transportationandstorageofNIOXMINO
whenitisdisconnectedfromthepower
outlet.(TheNIOXMINOBagissold
separately).
Operating conditions
Ambienttemperature:+16to+30°C
Humidity:20to60%RH(non-condensing)*
Atmosphericpressurerange:700to1060hPa
AmbientNOconcentration:<300ppb
Exhaledowrateduringmeasurementsat50
ml/s±10%BTPS(BodyTemperaturePressure
Saturated,37˚C,1013hPa,100%RH)
*TheambientRHintheinstrumentcanbeviewed
intheinformationmenu,seepage10andmay
differfromRHmeasuredoutsidetheinstrument.
