2. Move the handle to the operating area.
3 determine the driving direction,
4 Twist the accelerator on the handle
Removal/assembly of drive assembly
Preliminary steps
1．Safely park the vehicle and remove the shell
2. Close key and emergency stop switch.
3. Disconnect the battery connector.
program
1. Remove steering wire rope assembly (7).
2 remove the steering shaft screw (5) and remove the steering shaft (6)
3. Lift the whole vehicle with the weight of 585KG.
4. Disconnect the connecting terminals of the driving motor and the electromagnetic brake, and put
the vehicle into a stop.
5. Remove the fixing screw (8) of the drive assembly and lift the whole vehicle to remove the drive
assembly.
6. Remove the slewing support fixing screw (10) to remove the slewing support and connecting plate
(13)
Follow the steps in reverse order to install the drive assembly
