7 Schematic diagram
7-1 Hydraulic schematic
number Codename name number Codename name
1 A Hydraulic power unit
(motor and oil pump)
5 E Throttle valve
2 B Check valve 6 F Cylinder
3 C Solenoid valve 7 G Safety valve
4 D The overflow valve
