8 Charger
8-1 Lithium battery charger
8-1-1 Lithium battery charger introduction
WT2425ZMB type charger, this charger is an efficient, fast, small-sized,
floor-standing charging device with CAN communication. The charger adopts
two-phase AC 220V voltage input and adopts forced air cooling. It has input
over-voltage, under-voltage, output over-voltage, under-voltage, over-current, output
short-circuit, fan failure protection functions, and meets RoHS and CE requirements
8-1-2 Technical parameters of lithium battery charger
Input
voltage
（VAC）
Input
Current（A）
Power factor Overall
efficiency
Rated output
voltage (V)
Rated output
current (A)
220±15%
VAC
≤9 ≥0.9 ≥93% 24±0.5 25±0.5
A、Input to the chassis Withstand voltage AC2000V ，Leakage current <20mA；
B、Output to case Withstand voltage AC1000V， Leakage current <20mA；
C、Input to output Withstand voltage AC2000V ，Leakage current <20mA；
D、Insulation resistance test，The input is not less than 20MΩ/DC 500V。
