Nobles SPEED EX - Machine Specifications

OPERATION EN
13
Nobles Speed Ex (03--08)
MACHINE SPECIFICATIONS
MODEL Speed Ex
LENGTH 26.8 in / 680 m m with handle folded
WIDTH 19.3 in / 490 mm
HEIGHT 27.9 in / 709 m m with handle folded
WEIGHT 102 lb / 46.3 kg
SOLUTION TANK CAPACITY 5 gal / 19 L
RECOVERY TANK CAPACITY 5 gal / 19 L
PRODUCTIVI TY RATE -- AVG. 950 ft
2
/88m
2
/hr
CLEANING PA TH WIDTH 15 in/ 380 mm
BRUSH PRESSURE 25 lb/ 11.3 kg
BRUSH MOTOR 120V, .4 hp/ .3 kW , 3. 2 A, 1200 brush rpm
VACUUM MOTOR 120V, 1.2 hp/ .88 kW , 2--stage 5.7, 7.1 A
WATER LIFT--AIR FLOW 86 in / 2184 m m
SOLUTION PUMP 120V, 0.11 hp/ 0.081 kW, 2--stage 5.7, 0.7 A
SOLUTION FLOW RATE .7 gal / 2.7 L/mi n
VOLTAGE 120 AC
TOTAL POWER CONSUMPTION 10.8 A
POWERCORDLENGTH 50 ft/15 m
DECIBEL RATING AT OPERATOR’S EAR, INDOORS* 69 dBA
PROTECTION GRADE IPX3
VIBRATI ONS AT CONTROLS <2.0 m/ s2
*Sounds levels (ISO 1 1201) as recommended by the American Association of Cleaning Equipment Manufactures (AACEM) and OSHA.
