Nokia 2300 Service Manual

nokia
CONNECTING PEOPLE
PAGE 7 (21) Approved 1.0
Customer Care EMEA DJk
Technical Services Confidential 26.01.2004
Repair Concepts
Service Manual 2300 Level 1&2 Copyright 2003-2004 © Nokia Corporation
5. SPARE PARTS LIST
MECHANICAL PARTS
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
I001 1 XXXXXXX A-COVER SUB ASSY
I002 1 XXXXXXX KEYMAT
I003 6 6290083 SCREW 1.8X5.3 T6+
1 4850365 LCD ASSY
I004 1 - C-COVER
I005 1 5140233 SPEAKER
I006 1 - LCD INCL. LIGHTGUIDE
I007 1 9795147 DOME SHEET
I008 1 - ENGINE MODULE
I009 1 - SHIELDING
I010 1 5140201 MICROPHONE
I011 1 5460119 SYSTEM CONNECTOR
I012 1 6800053 VIBRA MOTOR
1 9492069 D-COVER ASSY
I013 1 - IHF MODULE
I014 1 - D-COVER
I015 1 - ANTENNA
I016 1 - SIM LID
I017 1 - D-COVER LOGO BADGE
I018 1 - TYPE LABEL
I019 1 XXXXXXX BATTERY-COVER
SOLDERING COMPONENTS ONLY FOR LEVEL 2
ITEM/
CIRCUIT REF.
QTY PART NO PART NAME
F100 1 5119019 SM FUSE F 1.5A 32V

Nokia 2300 Specifications

General

Network Technology	GSM
2G bands	GSM 900 / 1800
EDGE	No
SIM	Mini-SIM
Status	Discontinued
Display type	Monochrome graphic
Resolution	96 x 65 pixels
Memory Card slot	No
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Clock	Yes
Alarm	Yes
Java	No
SMS to many	Yes
Calculator	Yes
Stopwatch	Yes
Weight	92 g
Sound Alert types	Vibration
Predictive text input	Yes
Battery type	BL-5C
Dimensions	107 x 46 x 20 mm, 81 cc (4.21 x 1.81 x 0.79 in)
