Nokia 2300 Service Manual

nokia
CONNECTING PEOPLE
PAGE 15 (21) Approved 1.0
Customer Care EMEA DJk
Technical Services Confidential 26.01.2004
Repair Concepts
Service Manual 2300 Level 1&2 Copyright 2003-2004 © Nokia Corporation
10. LEGEND FOR QUICK TROUBLE SHOOTER
This legend is valid for all parts of the Quick Trouble Shooter
Follow the steps until the problem is solved. If this doesn’t help, you are not authorized to go forward.
Only underlined components ( e.g.
I002) can be changed.
The start point of repair activities regarding the appeared fault symptoms.
Follow the arrows step by step
Pads or contacts: Check optical and mechanical condition particularly
regarding to corrosion. Clean if necessary.
Measure component for electrical functionality and change, if needed.
(Level 2 only)
Pads or contacts: Check optical and mechanical condition particularly
regarding to corrosion. Clean with ESD brush only, if necessary.
No more actions possible send product to the appropriate service partner
with higher service level.

Nokia 2300 Specifications

General

Network Technology	GSM
2G bands	GSM 900 / 1800
EDGE	No
SIM	Mini-SIM
Status	Discontinued
Display type	Monochrome graphic
Resolution	96 x 65 pixels
Memory Card slot	No
Phonebook	Yes
Call records	10 dialed, 10 received, 10 missed calls
Loudspeaker	No
3.5mm jack	No
Messaging	SMS
Clock	Yes
Alarm	Yes
Java	No
SMS to many	Yes
Calculator	Yes
Stopwatch	Yes
Weight	92 g
Sound Alert types	Vibration
Predictive text input	Yes
Battery type	BL-5C
Dimensions	107 x 46 x 20 mm, 81 cc (4.21 x 1.81 x 0.79 in)
