Nokia 7210 SAS-M User Manual

System Management
308
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Table 39 LED Functionality for 7210 SAS and 1830 VWM (CWDM)
Events 7210 SAS
major alarm
LED
Optical shelf
controller LED
Optical shelf line
card LED
Shelf admin up and shelf
is physically connected to
7210 SAS
The shelf becomes
operational up by default
No color Green Amber/green based
on whether line card
provisioned correctly
or not
Shelf is operationally up No color Green Amber/green based
on whether card-type
provisioned correctly
or not
Line card admin up and
operational down when
card-type not provisioned
correctly (that is,
mismatch between
provisioned and equipped
type)
Red Green Amber for that line
card LED
Line card admin up and
operational up when card-
type correctly provisioned
No color Green Green for that line
card LED
Line card removed Amber LED
glows
Green No LED glows (line
card is removed)
Line card inserted back No color Green LED turns to green
Table 40 LED Functionality for 7210 SAS and 1830 VWM (DWDM)
Events 7210 SAS
major alarm
LED
Optical shelf
controller LED
Optical shelf line
card LED
Shelf admin up and shelf is
physically connected to
7210 SAS. The shelf
becomes operational up by
default
No color Green Amber/green based
on whether line card
provisioned correctly
or not
