Appendix: 7210 SAS Boot Procedures
692
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
Step 12. At the prompt, enter admin for the default username and password, and
log into the 7210 SAS device.
7.2.2 Procedure to Boot from the Network in Manual
Mode Using Uplink Ports
Perform this procedure to boot a 7210 SAS device from the network without using
the auto-init mode.
The front panel ports (referred to as uplinkA and uplinkB in the sample output used
in this procedure) are used to boot the device from the network.
Perform the following steps to boot from the network in the manual mode using uplink
ports.
Step 1. Power on the 7210 SAS device.
Step 2. Use the uplink ports to boot from the network.
Nokia SASDxp 7210 Boot ROM. Copyright 2000-2020 Nokia.
All rights reserved. All use is subject to applicable license agreements.
Build: X-20.3.B1-1 on Wed Feb 12 15:29:18 IST 2020 by sasbuild
Version: 0x8
SASDxp-DC Board
Shmoo tuning data in flash is valid, load it
DDR Tuning Complete.
Passed!
Note: The SYS LED is green after the device has successfully completed the boot process
and is running normally.
Note: This procedure is supported on all 7210 SAS platforms, except the 7210 SAS-R6 and
7210 SAS-R12, and all platforms configured in the satellite mode of operation.
Note: Refer to the corresponding 7210 SAS chassis installation guide for information about
equipment required to setup the device.
Note: Nokia recommends that the TiMOS image should be stored on the internal flash so
that it is available for use in the case where booting the system from the flash is required
later on subsequent reboot.
