7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 391
Description
This command administratively disables the entity. When disabled, an entity does not
change, reset, or remove any configuration settings or statistics.
The operational state of the entity is disabled as well as the operational state of any entities
contained within. Many objects must be shut down before they may be deleted.
The no form of this command places the entity into an administratively enabled state.
Default no shutdown
Special Cases PTP Protocol Handling — Applies only to 7210 SAS-Mxp. When the no shutdown
command is issued in the configure>system>ptp context, resources are allocated
to enable processing of the protocol by the node. When the shutdown command is
issued in the configure>system>ptp context, the resources are deallocated.
description
Syntax description description-string
no description
Context config>system>cron>sched
config>system>cron>time-range
config>system>cron>tod-suite
config>system>script-control>script
config>redundancy>multi-chassis>peer
Supported
Platforms
Supported on all 7210 SAS platforms as described in this document, including platforms
configured in the access-uplink operating mode
Description
This command creates a text description stored in the configuration file for a configuration
context.
Note: The config>redundancy>multi-chassis>peer and config>redundancy>multi-
chassis>peer>mc-lag contexts are not supported on 7210 SAS platforms configured in the
access-uplink operating mode
Note: Resources for PTP are allocated when the protocol is enabled in the base routing
instance. Resources are deallocated when the configuration of the last PTP context under
the base routing instance is shutdown
Note: The config>redundancy>multi-chassis>peer context is not supported on
7210 SAS platforms configured in the access-uplink operating mode
