7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 589
Table 69 Output Fields: System Information
Label Description
System Name The configured system name
System Type Indicates whether or not the node is operating in a virtual chassis
Chassis-role Config
value
Supported only on 7210 SAS-Sx/S 1/10GE devices. Displays the
configured value for boot parameter chassis-role
Host-type Config
value
Supported only on 7210 SAS-Sx/S 1/10GE devices. Displays the
configured value for BOF parameter host-type
Chassis Operating
Mode
The current operating mode of the node/chassis
It can be in satellite mode, standalone mode, or standalone-vc
mode depending on the configuration of the chassis-role and
host-type parameters.
Supported only on 7210 SAS-Sx 1/10GE devices
Software Version Indicates the version of the software
System Contact A text string that describes the system contact information
System Location A text string that describes the system location
System Coordinates A text string that describes the system coordinates
System Active Slot Indicates which slot is used for the active CPM (CPM-A or CPM-
B)
System Up Time The time since the last boot
SNMP Port The port number used by this node to receive SNMP request
messages and to send replies
SNMP Engine ID The SNMP engineID to uniquely identify the SNMPv3 node
SNMP Engine Boots The number of time the SNMP agent has restarted
It is typically equivalent to the number of times the node has
rebooted.
SNMP Max Message
Size
The maximum SNMP packet size generated by this node
SNMP Admin State Enabled — SNMP is administratively enabled and running
Disabled — SNMP is administratively shut down and not running
SNMP Oper State Enabled — SNMP is operationally enabled
Disabled — SNMP is operationally disabled
SNMP Index Boot
Status
Persistent — System indexes are saved between reboots
Not Persistent — System indexes are not saved between reboots
