Nokia 7210 SAS-M User Manual

7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
System Management
Edition: 01 3HE 16132 AAAB TQZZA 617
Table 75 Output Fields: System PTP
Label Description
Clock Type Displays the local PTP clock type:
• ordinarySlave — The system is always a slave clock in the
master-slave hierarchy. The system derives its timing from
one or more master clocks in the network.
• ordinaryMaster — The system is a grandmaster clock in the
master-slave hierarchy. The system provides timing to
multiple slave clocks in the network.
• boundary — The system is a boundary clock, which may be
anywhere in the master-slave clock hierarchy. It can obtain
timing from a master clock, and provide timing to multiple
slave clocks.
• transparent-e2e
PTP Profile Displays the PTP profile: ieee-1588, itu-telecom-freq,
g8275dot1- 2014, or g8275dot2-2016
Domain Displays the PTP device domain
Network Type Indicates whether SONET or SDH values are being used for
encoding synchronous status messages
Local Clock
Admin State Up — The local PTP clock is administratively enabled
Down — The local clock is administratively shut down and not
running
Oper State Up — The local clock is operationally enabled and running
Down — The local clock is operationally disabled and not running
Announce Interval Displays the configured announce interval value
Announce Rx
Timeout
Displays the configured announce Rx timeout value
Clock Id Displays a unique 64-bit number assigned to the clock
Clock Class Displays the local clock class
Clock Accuracy Displays the local clock accuracy designation
Clock Variance Displays the local clock variance
Clock Priority1 Displays the first priority value of the local clock, used by the Best
Master Clock Algorithm (BMCA) to determine which clock should
provide timing for the network
