Nokia 7210 SAS-M User Manual

System Management
624
7210 SAS-M, T, R6, R12, Mxp, Sx, S Basic System
Configuration Guide
3HE 16132 AAAB TQZZA Edition: 01
port
Syntax port port-id [detail]
Context show>system>ptp
Supported
Platforms
7210 SAS-M (network and access-uplink), 7210 SAS-Mxp, 7210 SAS-R6, 7210 SAS-R12,
7210 SAS-Sx 10/100GE, 7210 SAS-T (network and access-uplink)
Description This command displays PTP port information.
Parameters port-id — Specifies the port ID.
Values slot/mda/port
detail — Displays detailed information.
Output The following output is an example of PTP port information, and Table 78 describes the
output fields.
Sample Output
A:bksim1618# show system ptp port
===============================================================================
IEEE 1588/PTP Ethernet Port Summary Information
Sync Interval Displays the configured sync interval value
Local PTP Port Displays the local PTP port
PTP Port State Displays the PTP port state
Remote PTP Port Displays the PTP port number at the remote end
Clock ID Displays the clock identity value of the local PTP clock
GM Clock Class Displays the grand master clock class
GM Clock Accuracy Displays the grand master clock accuracy designation
GM Clock Variance Displays the grand master clock variance
GM Clock Priority1 Displays the grand master clock priority1 designation
GM Clock Priority2 Displays the grand master clock priority2 designation
Steps Removed Displays the number of hops from GM
Parent Clock yes — if the peer is the chosen parent clock
no — if the peer is not the chosen parent clock
Table 77 Output Fields: PTP Peers (Continued)
Label Description
