Nokia 7368 ISAM CPE - Figure 17 LAN Settings Window; Table 17 LAN Parameters

Configure a A-020W-A
54
7368 ISAM CPE A-020W-A Product Guide
3FE-47511-AAAA-TCZZA Issue: 01
•
TR-069
• QoS Configuration
Procedure 13 LAN configuration
1 Select Network > LAN from the top-level menu in the Ethernet Gateway window, as shown
in Figure 17.
Figure 17 LAN settings window
Table 17 describes the fields in the LAN window.
Table 17 LAN parameters
Field Description
IPv4 Address IP Address of the A-020W-A CPE
Subnet Mask Subnet mask of the A-020W-A CPE
DHCP enable Select this check box to enable DHCP
DHCP Start IP Address Starting DHCP IP address
(1 of 2)
