7368 ISAM CPE A-020W-A Product Guide Configure a A-020W-A
Issue: 01 3FE-47511-AAAA-TCZZA 81
5 Click Save DMZ.
6 STOP. This procedure is complete.
Procedure 29 Access control configuration
This procedure describes how to configure the access control level (ACL).
1 Select Security > Access Control from the top-level menu in the Ethernet Gateway window,
as shown in Figure 34.
Figure 34 Access Control window
Table 32 describes the fields in the Access Control window.
Note 1 — ACL takes precedence over the firewall policy.
Note 2 — The trusted network object will be shared for all WAN
connections; it is not applied individually to a WAN connection.
