7368 ISAM CPE A-020W-A Product Guide Configure a A-020W-A
Issue: 01 3FE-47511-AAAA-TCZZA 65
2 Configure the Wireless connection.
3 If you have enabled and configured WPS, click WPS connect.
4 Click Save.
5 STOP. This procedure is complete.
Procedure 19 Wireless scheduling
1 Select Network > Wireless Schedule from the top-level menu in the Ethernet Gateway
window, as shown in Figure 23.
Figure 23 Wireless Schedule window
2 Select the Schedule Function check box to turn the wireless signal off for the configured
period.
3 Click the plus sign (+) to add a scheduling rule.
A separate panel appears for configuring wireless schedule rules.
4 Enter a start time and end time for the period in which you want the wireless signal off.
Release 05.08.01 | June 2018 | Edition 01
