Configure a G-240W-G indoor ONT
112
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Figure 44 US Classifier Policy window
Table 35 describes the fields in the US Classifier Policy window.
Table 35 US Classifier Policy parameters
2 Select a tunnel interface.
3 Enter a VLAN ID and priority level.
Field Description
Tunnel Type The tunnel type is set to GRE and cannot be modified.
Tunnel Interface Choose a tunnel interface from the drop-down menu: No Tunnel, GRE
Tunnel, or LAN traffic.
VLAN ID Enter a VLAN ID (0-4094).
VLAN Tag This field is not configurable. The VLAN tag is set to 8100 (hexadecimal).
VLAN Priority Enter a VLAN priority level (0 to 7). A lower number indicates a higher
priority.
IP TOS/DSCP This field is not configurable. All tunnel packets are generated with a
default DSCP value (usually 0).
Drop Select this checkbox to drop the packets
Release 05.08.01a | August 2018 | Edition 01
