Nokia 7368 - Figure 33 WAN Network Window; Table 26 WAN Network Parameters

Configure a G-240W-G indoor ONT
94
7368 ISAM ONT G-240W-G Product Guide
3FE-47555-AAAA-TCZZA Issue: 01
Procedure 17 WAN networking configuration
1 Select Network > WAN from the top-level menu in the GPON Home Gateway window, as
shown in Figure 33.
Figure 33 WAN network window
Table 26 describes the fields in the WAN network window.
Table 26 WAN network parameters
Field Description
WAN Connection List Choose a WAN connection from the drop-down menu to set the
connection parameters
Connection Type Choose a connection type: IPoE or PPPoE
IP mode Choose an IP mode from the drop-down menu: IPv4 or IPv6
Enable/Disable Select this checkbox to enable the WAN connection
(1 of 2)
Release 05.08.01a | August 2018 | Edition 01
