7368 ISAM ONT G-240W-G Product Guide G-240W-G unit data sheet
Issue: 01 3FE-47555-AAAA-TCZZA 47
Table 6 describes the physical connections for G-240W-G indoor ONTs.
Table 6 G-240W-G indoor ONT physical connections
Note
(1)
The primary path for the earth ground for these ONTs is provided by the 12V Return signal in the power
connector.
4.5 G-240W-G LEDs
Figure 13 shows the G-240W-G indoor ONT LEDs.
Connection
(1)
Description
POTS ports This connection is provided through RJ-11 ports. Up to two POTS connections are
supported.The POTS ports support voice services.
Ethernet ports This connection is provided through Ethernet RJ-45 connectors. Up to four 10/100/1000
Base-T Ethernet interfaces are supported.The Ethernet ports can support both data and
in-band video services on all four interfaces.
USB ports This connection is provided through 2 USB ports. The ONT supports external USB hard
drives that can be made accessible to all LAN devices.
WPS button The Wi-Fi Protected Setup button is labeled as WPS. This button enables and disables
WLAN data encryption.
WLAN button Wi-Fi service is compliant with IEEE 802.11 standards and is enabled and disabled using
the WLAN button.
LED On/Off
button
This button, located on the side of the ONT, turns all LED indicators on or off.
Reset button Pressing the Reset button for less than 10 seconds reboots the ONT; pressing the Reset
button for 10 seconds resets the ONT to the factory defaults, except for the LOID and SLID.
Power input This connection is provided through the power connector. A power cable fitted with a barrel
connector is used to make the connection.
On/Off button This button turns the ONT on or off.
Fiber optic port This port provides the connection for the fiber optic cable.
