21
General information
Use the infrared port for connecting to a compatible PC, printer, digital camera, or
another communicator.
To charge the battery
Note: See important safety information on battery usage on page 22.
Tip: To check the current
battery level, see the battery
indicator on the
communicator or phone
display.
1 Connect the charger cable to the bottom of the communicator, as shown in
Figure 8.
Figure 8
2 Connect the charger to the proper voltage AC wall outlet. While charging is in
progress, the battery level indicator scrolls on the phone display.
3 When the battery is fully charged, the bars stop scrolling and four bars are
displayed. You may now remove the charger plug from the communicator.
Note: You can use all the features of the communicator during charging.
