5 Construction
FlexiZoneIndoorPicoBTSconsistsofthefollowingparts:
•
Core base station module
Thecoremoduleintegratesthefollowingitemsintoonesingleunit:
–
RF
–
basebandfunctionality
–
clockandcontrol
–
externalinterfaces
–
transmission
SomevariantsalsocontainanintegratedWi-FiantennathatenablesFlexiZone
IndoorPicoBTStofunctionasawirelessAccessPoint(AP).SeeTable6:FlexiZone
PicoIndoorBTSsupportedLTEbandwidthvariantsforavailablemodelslist.
•
Base station contents of delivery
1. MountingBracket
2. Ceilingclipwithscrews
3. Tamper-resistantscrewandamagnetizedwrench
4. Quickstartguide
Figure2
Contentsofdelivery


•
Base station ancillary options (not included in the box)
–
poweradapterwithpowercable
–
remoteRFGPSantenna
–
externalantenna(onlyformodelswithoutinternalantenna)
–
PoE-++powerinjector
TheFlexiZonePicoIndoorBTSisacompleteBTSwithEthernettransport.Thetotal
volumeoftheBTSis2.8litersandtheweightoftheunitis1.9kg(unitswithoutWi-Fi)or
2.2kg(unitswithWi-Fi).
5.1 Interfaces
ThischapterdescribesinsterfacesoftheFlexiZonePicomodule.
Construction FlexiZoneIndoorPicoBTSProductDescription
10 DN09210454 Issue:01
 
