Figure7
MountingFlexiZoneIndoorPicoontoawall
Flexi Zone Indoor Pico pole installation
g
FlexiZoneIndoorPicocanbemountedontoaverticalorhorizontalindoorpole.
g
UsethemountingbracketdeliveredintheboxandbandstrapstoinstalltheFlexiZone
IndoorPicoBTSontoapole.
g
Thebandstrapsarenotincludedwithinthepackageandneedtobeordered
separately.
Figure8
MountingFlexiZoneIndoorPicoontoapole
FlexiZoneIndoorPicoBTSProductDescription Construction
Issue:01 DN09210454 15
