Nokia Flexi Zone Pico - Table 6 Flexi Zone Pico Indoor BTS Supported LTE Bandwidth Variants; Table 7 Flexi Zone Pico Indoor BTS Supported WCDMA Bandwidth Variants

Table6
FlexiZonePicoIndoorBTSsupportedLTEbandwidthvariants(Cont.)
Duplex
Mode
Operating
Band
Uplink (UL)
operating band
BTS receive
UE transmit
Downlink (DL)
operating band
BTS transmit
UE receive
Unit's
name
Integrated
Wi-Fi
Antenna
F
UL_low
–
F
UL_high
F
DL_low
–
F
DL_high
28
703MHz-748
MHz
758MHz-803
MHz
FWPC Yes Embedded
FWPD No Embedded
FWPE No External
TDD
40 2300MHz-2400MHz
FWNA Yes Embedded
FWNB No Embedded
FWNC No External
41 2496MHz-2690
FWHJ Yes Embedded
FWHK No Embedded
FWHL No External
42 3400MHz-3600MHz
FWQB Yes Embedded
FWQC No Embedded
FWQD No External
TheWCDMAsupportedbandwidthisshowninTable7:FlexiZonePicoIndoorBTS
supportedWCDMAbandwidthvariants.
Table7
FlexiZonePicoIndoorBTSsupportedWCDMAbandwidthvariants
Operating
Band
Uplink (UL)
operating band
BTS receive
UE transmit
Downlink (DL)
operating band
BTS transmit
UE receive
Variant Integrated
Wi-Fi
Antenna
F
UL_low
–
F
UL_high
F
DL_low
–
F
DL_high
1
1920MHz-1980
MHz
2110MHz-2170
MHz
FWFE Yes Embedded
FWFF No Embedded
FWFG No External
2
1850MHz-1910
MHz
1930MHz-1990
MHz
FWGL Yes Embedded
FWGM No Embedded
FWGN No External
AirInterface FlexiZoneIndoorPicoBTSProductDescription
18 DN09210454 Issue:01
 
