Flash concept with FPS-10
Figure 4 Basic flash concept with FPS-10
Type Description
Product specific devices
FS-37 Flash adapter
Other devices
FPS-10 Flash prommer box
PKD-1/PK-1 SW security device
SS-46 Interface adapter
PC with Phoenix service software
Cables
XCS-4 Modular cable
CA-35S Power cable
USB cable
RM-179; RM-223
Service Tools and Service Concepts
Page 2 –18 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
