Nokia N81 - Service Concept for RF Testing and RF;BB Tuning

Type Description
GPIB control cable
Service concept for RF testing and RF/BB tuning
Figure 10 Service concept for RF testing and RF/BB tuning
Type Description
Product specific devices
MJ-114 Module jig
Other devices
CU-4 Control unit
PKD-1/PK-1 SW security device
SX-4 Smart card
Measurement equipment
Smart card reader
PC with Phoenix service software
Cables
DAU-9S MBUS cable
PCS-1 DC power cable
RM-179; RM-223
Service Tools and Service Concepts
