Type Description
Smart card reader
Cables
CA-89DS Cable
PCS-1 DC power cable
XRS-6 RF cable
USB cable
Bluetooth test concept with SB-6
Figure 14 Bluetooth test concept with SB-6
Type Description
Product specific tools
FS-37 Flash adapter
Other tools
CU-4 Control unit
PKD-1 SW Security device
SS-62 Generic base adapter
SB-6 BT test box
ACP-8 Charger for SB-6
Cables
PCS-1 Power cable
DAU-9S Cable
RM-179; RM-223
Service Tools and Service Concepts
Page 2 –28 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
