Type Description
Cables
DAU-9s MBUS cable
PCS-1 DC power cable
XRS-6 RF cable
USB cable
RF/BB tuning and flashing with FPS-10
Figure 12 RF/BB tuning and flashing with FPS-10
Type Description
Product specific tools
MJ-114 Module jig
Other tools
CU-4 Control unit
FPS-10 Flash prommer box
PKD-1/PK-1 SW security device
SX-4 Smart card
Measurement equipment
PC with Phoenix service software
RM-179; RM-223
Service Tools and Service Concepts
Page 2 –26 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
