Flash concept with FLS-5 and SS-62
Figure 7 Basic flash concept with FLS-5 and SS-62
Type Description
Product specific tools
FS-37 Flash adapter
Other tools
CU-4 Control unit
FLS-5 POS flash dongle
SS-62 Flash adapter base
PC with Phoenix service software
Cables
CA-89DS Cable
PCS-1 Power cable
Standard USB cable
USB cable
RM-179; RM-223
Service Tools and Service Concepts
Issue 1 COMPANY CONFIDENTIAL Page 2 –21
Copyright © 2007 Nokia. All rights reserved.
