Nokia RM-243 Service Manual

Figure 42 Camera flash and driver design
Secondary camera characteristics
Sensor type CMOS
Sensor photo detectors (effective) 384x320
F number/Aperture 2.8
Focus range 25cm -> 1m
Still image resolutions 320x240
Still images format EXIF (.jpg)
Video resolutions 176x144 or 128x96
Video clip length 30sec short mode or 1 hour free mode
Video file format 3GPP, (*.3gp)
Exposure control Automatic
White Balance Automatic
Colours 16.7 Million, 24bit
User interface
Display module
Display module
The display in RM-243 is an active TFT QVGA display that supports up to 16.777.216 colors (320x240 pixels).
The interconnection between the LCD module and the engine is implemented with a 24-pin board-to-board
connector.
RM-243
System Module and User Interface
Page 6 –16 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
