Page #98 background imageLoading...
Page #98 background image
General voltage checking
Steps
1. Set up the main board in the module jig. The phone should be in local mode.
2. Check the following:
# Signal name Test point Voltage (all bands)
1 VCTCXO supply R7501 2.5 V
2 AHNEUS supply from DC/DC conv C7590 3.2 V
3 FEM supply L7510 3.9 V
4 WCDMA PA supply from DC/DC conv C7543 0 V (1.3 V* when transmitting. Settings
as in note below)
5 Vbat at WCDMA PA C7547 3.9 V
6 Supply input to DC/DC conv L7592 3.9 V
* With these settings, the result should be 1.3 V.
RM-243
RF troubleshooting
Page 4 –8 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
