Nomadix AG3100 - Sample SYSLOG Report

To Next Page

To Previous Page

ACCESS GATEWAY

Quick Reference Guide 241

Sample SYSLOG Report

Syslog reports are generated by the Access Gateway and sent to the syslog server that is assigned to general

error detection and reporting.

2003-02-10 11:25:53 Local2.Info 1.2.3.4 INFO [Access Gateway v51.4.126]

DHCP: ndxDHCPInit: 0021 DHCP initialized

2003-02-10 11:25:53 Local2.Info 1.2.3.4 INFO [Access Gateway v51.4.126]

CLISRD: 0206 Setting COM1 to 9600 baud

2003-02-10 11:25:53 Local2.Info 1.2.3.4 INFO [Access Gateway v51.4.126]

CLISRD: Starting CLI on the serial port

2003-02-10 11:25:53 Local2.Info 1.2.3.4 INFO [Access Gateway v51.4.126]

INIT: Access Gateway v51.4.126 with ID 010384 Initialized
