norbar PNEUTORQUE PT 9 - Tool Dimensions

19
Model
Dimensions (mm)
A
B
C minimum
C maximum
Single speed
MTS
AUT
Single
speed
MTS / AUT
PT 1 (¾”)
108
368
454
437
83
83
217
PT 1 (1”)
108
373
459
442
83
83
217
PT 1A
108
373
459
442
83
83
217
PT 2
108
373
459
442
83
83
217
PT 5
119
424
510
493
83
86
264
PT 6
119
430
516
499
83
86
264
PT 7
144
457
543
526
146
146
333
PT 9
184
452
538
521
169
169
351
PT 11
212
555
641
-
-
-
500
PT 12
240
593
679
-
Blank plate
PT 13
315
636
716
-
Blank plate
PT 14
315
724
810
-
Blank plate
PT 15
-
-
-
-
Application specific
PT 16
410
780
866
-
Application specific
PT 17
410
853
939
-
Application specific
PT 18
520
850
936
-
Application specific
Due to continuous improvement all specifications are subject to change without prior notice.
FIGURE 14 – Standard series tool (smaller)
FIGURE 15 – Standard series tool (larger)
A
B
FIGURE 16 – PT 15 – 18
