SPECIFICATIONS
General
Repeatability: ± 5%.
Air Supply: Maximum pressure 6.0 bar (For maximum torque capacity).
Air consumption 19 litres / sec (40 ft³/m [CFM]).
Recommended Lubrication: Fuchs Silkair VG22 or Shell Tellus S2 VX15 for the Lubro Control Unit.
Temperature Range: 0°C to +50°C (operating). -20°C to +60°C (storage).
Maximum Operating Humidity: 85% Relative Humidity at 30°C.
Maximum Vibration at Handle: < 2.5m/s² measured in accordance with ISO 28927-2. Measured tool
vibration (ah) = 0.444 m/s² with uncertainty (K) = 0.14 m/s²
Sound Pressure Level: The sound pressure level is 81 dB(A) uncertainty K = 3dB, measured in
accordance with BS EN ISO 11148-6
Environment: Indoor & dry outdoor use within a light industrial environment.
Standard Series
Model
Torque
Free Speed
(At maximum air pressure)
Weight (kg)
Tool
Reaction
Minimum
Maximum
Single
speed
MTS / AUT
Single
speed
MTS /
AUT
PT 1
160 N∙m
(120 lbf∙ft)
680 N∙m
(500 lbf∙ft)
30 rev/min
150 rev/min
10.6
14.1
2.2
PT 1A
270 N∙m
(200 lbf∙ft)
1200 N∙m
(900 lbf∙ft)
15 rev/min
75 rev/min
11.1
14.6
2.2
PT 2
515 N∙m
(380 lbf∙ft)
1700 N∙m
(1250 lbf∙ft)
9 rev/min
45 rev/min
11.1
14.6
2.2
PT 5
880 N∙m
(650 lbf∙ft)
3400 N∙m
(2500 lbf∙ft)
5 rev/min
25 rev/min
14.0
17.5
2.5
PT 6
880 N∙m
(650 lbf∙ft)
3400 N∙m
(2500 lbf∙ft)
5 rev/min
25 rev/min
14.0
17.5
2.5
PT 7
1762 N∙m
(1300 lbf∙ft)
6000 N∙m
(4500 lbf∙ft)
2.5 rev/min
12.5 rev/min
19.7
23.2
6.3
PT 9
2710 N∙m
(200 lbf∙ft)
9500 N∙m
(7000 lbf∙ft)
1.8 rev/min
9 rev/min
24.4
27.9
8.3
PT 11
4400 N∙m
(3250 lbf∙ft)
20000 N∙m
(14700 lbf∙ft)
1.2 rev/min
6 rev/min
38.6
42.1
13.3
PT 12
9500 N∙m
(7000 lbf∙ft)
34000 N∙m
(25000 lbf∙ft)
0.5 rev/min
2.5 rev/min
49.8
53.3
6.5
PT 13
13550 N∙m
(10000 lbf∙ft)
47000 N∙m
(35000 lbf∙ft)
0.3 rev/min
1.5 rev/min
102.2
105.7
6.9
PT 14
22375 N∙m
(16500 lbf∙ft)
100000 N∙m
(73500 lbf∙ft)
0.2 rev/min
1 rev/min
119.4
122.9
10.4
PT 15
35000 N∙m
(25825 lbf∙ft)
150000 N∙m
(110500 lbf∙ft)
0.1 rev/min
0.5 rev/min
-
-
-
PT 16
46500 N∙m
(34400 lbf∙ft)
200000 N∙m
(147500 lbf∙ft)
0.08 rev/min
0.4 rev/min
266.5
270
-
PT 17
58250 N∙m
(42990 lbf∙ft)
250000 N∙m
(184500 lbf∙ft)
0.07 rev/min
0.35 rev/min
281.5
285
-
PT 18
70000 N∙m
(51630 lbf∙ft)
300000 N∙m
(221270 lbf∙ft)
0.06 rev/min
0.3 rev/min
376.5
380
-
