5 Parameterisation
BU 0280 GB Subject to technical amendments 57
Parameter
{Factory setting}
Setting value / Description / Note Device Supervisor
Parameter
set
P161 ... [-01]
...
... [-02]
Config. process data for the bus
module
0 ... 1
{ 0 }
[-01] = Inputs
[-02] = Outputs
Possible values which can be set:
0 = Module does not transmit
1 = Data length 1 Byte
P162 ... [-01]
[-02]
... [-03]
Configuration of FI process data
0 ... 8
{ 0 }
[-01] = Status values
[-02] = Control values
Possible values which can be set:
0 = FI does not exist
1 = Data length in Bytes
…
8 = Data length in Bytes
[-03] = Profile
0 = AC drive profile 1
1 = AC drive profile 2
2 = NORDAC profile
P163 ... [-01]
[-02]
... [-03]
Configuration of FI 2 process data
0 ... 8
{ 0 }
[-01] = Status values
[-02] = Control values
Possible values which can be set:
0 = FI does not exist
1 = Data length in Bytes
…
9 = Data length in Bytes
[-03] = Profile
0 =
AC drive profile 1
1 = AC drive profile 2
2 = NORDAC profile
