Supplementary Manual DeviceNet for NORDAC SK 200E
58 Subject to technical amendments BU 0280 GB
Parameter
{Factory setting}
Setting value / Description / Note Device Supervisor
Parameter
set
P164 ... [-01]
[-02]
... [-03]
Configuration of FI 3 process data
0 ... 8
{ 0 }
[-01] = Status values
[-02] = Control values
Possible values which can be set:
0 = FI does not exist
1 = Data length in Bytes
…
10 =
Data length in Bytes
[-03] = Profile
0 =
AC drive profile 1
1 = AC drive profile 2
2 = NORDAC profile
P165 ... [-01]
[-02]
... [-03]
Configuration of FI process data
0 ... 8
{ 0 }
[-01] = Status values
[-02] = Control values
Possible values which can be set:
0 = FI does not exist
1 = Data length in Bytes
…
11 =
Data length in Bytes
[-03] = Profile
0 =
AC drive profile 1
1 = AC drive profile 2
2 = NORDAC profile
